Explore our export-standard thermal casement windows, ultra-slim sliding doors, security entryways, and architectural glazing profile assemblies.
A definitive technical standard for architects, facade consultants, commercial builders, and import distributors evaluating high-performance swing window fenestration systems.
At Window Wurx Industry Co., Ltd., all swing window profile extrusions are engineered exclusively from primary billet 6063 aluminum alloy. Utilizing precision heat treatment, profiles achieve a T5 or T6 temper rating, yielding tensile strength ≥ 205 MPa and yield strength ≥ 180 MPa. Unlike recycled secondary scrap alloy, primary 6063-T5 delivers uncompromised structural rigidity, preventing sash warping, hinge sagging, and frame deformation under extreme wind pressures up to 5000 Pa (equivalent to Category 5 hurricane force loads).
Uninsulated aluminum is a conductive metal with high thermal transmittance. Our high-tier swing window systems feature a dual-chamber thermal break structure connected by German-engineered Technoform PA66-GF25 (25% glass fiber reinforced polyamide) insulation strips. This thermal barrier decouples the interior and exterior aluminum profiles, reducing frame U-factors from 5.8 W/m²K down to 1.2 W/m²K, effectively preventing dew condensation, indoor heat loss in cold climates, and solar heat gain in tropical zones.
Information Gain Fact: The integration of multi-cavity EPDM continuous weather-stripping gaskets alongside 24mm PA66-GF25 thermal strips lowers building HVAC cooling loads by up to 34% annually, exceeding ASHRAE 90.1 standards and complying with European Energy Performance of Buildings Directive (EPBD) zero-carbon building targets.
| Performance Metrics | Standard Non-Thermal Swing | Commercial Thermal-Break Swing | Passive House Ultra-Insulated Swing |
|---|---|---|---|
| Frame Profile Thickness | 1.4mm - 1.6mm (6063-T5) | 1.8mm - 2.0mm (6063-T5/T6) | 2.2mm - 3.0mm Heavy Duty Structural |
| Thermal Transmittance (U-Value) | 4.5 - 5.2 W/m²K | 1.6 - 2.1 W/m²K | 0.8 - 1.1 W/m²K (Triple Glazed Argon) |
| Acoustic Insulation Rating (STC) | 28 dB - 32 dB | 36 dB - 40 dB | 42 dB - 48 dB (PVB Laminated Insulated) |
| Air Infiltration (ASTM E283) | Level 3 Standard | Class 4 (EN 12207 Certified) | Class 4 High Airtightness (<0.1 m³/h·m) |
| Water Resistance (ASTM E331) | 350 Pa | 700 Pa (EN 12208 Class E1050) | 1000 Pa Extreme Storm Rated |
| Hardware Integration | Standard Friction Stay / Single Latch | Multi-Point Locking (Siegenia / Hoppe) | Hidden Hinge Heavy Duty 150kg Multi-Point |
From custom profile die development to automated CNC fabrication, Window Wurx Industry Co., Ltd. delivers full-lifecycle OEM/ODM engineering support for global project specifications.
Our in-house design engineering department translates architectural blue-prints into millimetric 3D CAD models and BIM objects. For specialized commercial facades, we design custom profile extrusion dies within 12–15 business days, accommodating non-standard mullion angles, flush sash aesthetics, and integrated motorized louvers.
Profiles undergo multi-stage pre-treatment (chromate-free conversion) followed by electrochemically applied coatings. Choose from Qualicoat-certified AkzoNobel fluorocarbon (PVDF) spray finishing (resistant to UV chalking and salt-spray oxidation for 25+ years), anodized finishes (15–25 microns), or heat-transfer Italian woodgrain surface treatments.
Operating 3 fully automated production lines across our 20,000 m² Foshan facility, profile cutting and hinge-slot milling are executed on 5-axis German CNC machines. Corner joints feature pneumatic corner-crimping with dual-component structural epoxy injection, establishing complete corner shear strength and zero water seepage.
Proven OEM Manufacturing Legacy: Established in 1993 in Dali Town, Foshan — China's world-famous aluminum industrial hub — Window Wurx Industry Co., Ltd. employs over 150 skilled technicians. With rigorous ISO9001 quality management, our products are independently tested to meet AS2047 (Australia/New Zealand), CE EN 14351-1 (Europe), and ASTM/AAMA (North America) standard testing mandates.
Strategic market analysis for project developers, general contractors, and hardware importers planning multi-year window procurement campaigns.
Modern architectural trends favor maximal glass area to increase daylight penetration and uninterrupted outdoor vistas. Sourcing demand has pivoted aggressively toward concealed sashes, slim mullions (profile face widths under 45mm), and structural silicone glazing (SSG) systems where the aluminum frame is hidden behind the outer pane of glass.
Commercial real estate and high-end residential villas are rapidly adopting smart building management systems (BMS). Our OEM swing windows can be pre-wired with integrated linear chain actuators, electric motorized openers, smart rain-wind sensors, and magnetic reed contacts for automated security alarm interfacing.
With the implementation of the European Union's Carbon Border Adjustment Mechanism (CBAM), carbon footprint verification is becoming mandatory. We offer options for hydro-powered low-carbon aluminum billets (<4.0 kg CO2/kg Al), allowing developers to accumulate LEED v4 and BREEAM sustainability certification credits.
Pure outward swing windows are expanding into multi-mode functionality: Tilt & Turn (inward tilting for draft-free top ventilation, full inward swing for safe cleaning), Parallel Pop-Out Windows (offering perimeter micro-ventilation with maximum burglar security), and Heavy-Duty Outward Awning Casement hybrids.
Ensuring zero surface scratch, zero glass breakage, and zero moisture corrosion during cross-border maritime shipping.
Layer 1: Protective PE masking film applied over all exposed aluminum frame surfaces.
Layer 2: Heavy-duty shock-absorbing foam corner protectors fitted to all 4 sash corners.
Layer 3: Full wrap with moisture-proof EPE Pearl Cotton foam sheeting.
Layer 4: Multi-layer corrugated cardboard wrap and waterproof stretch film encapsulation.
Layer 5: Fumigation-free ISPM-15 compliant plywood crates with internal rubber dampening pads, secured inside ocean shipping containers using steel straps.
Addressing common technical, logistics, compliance, and custom ordering questions for global buyers.
Partner with Window Wurx Industry Co., Ltd. — Foshan's trusted OEM/ODM manufacturer since 1993. Submit your architectural schedules, CAD drawings, or project specifications today for a factory-direct quote and complimentary technical consultation.
