Explore our export-grade aluminium door and window solutions manufactured to CE, AS2047, and ISO9001 standards. Tailored for luxury villas, commercial towers, and high-rise developments.
Engineered with heavy-duty multi-track stainless steel rails, PA66GF25 thermal barrier strips, and stackable sliding panels designed for massive seamless villa openings.
Ultra-narrow 16mm visible sightline profiles, concealed hinges, magnetic locking mechanisms, and tempered safety glass for minimalist interior and exterior entrances.
Strictly tested to AS2047 and AS1288 standards. Features double argon-filled low-E glass, high structural deflection resistance, and commercial anodized finishes.
Acoustic-rated up to 48dB with laminated glass configurations and concealed aluminum internal framing for dynamic corporate office space division.
Extruded double-wall aluminum slats with high-density polyurethane insulation foam core, heavy-duty smart tubular motors, and wind-resistant side guide tracks.
Corrosion-resistant T5/T6 alloy profiles with custom powder-coating, engineered for greenhouse structures, sunroom enclosures, and custom window glazing.
Designed for coastal wind-load exposure up to 4500Pa. Equipped with drainage sub-sills, EPDM weather-strip gaskets, and multipoint anti-burglary locks.
SGP laminated impact glass combined with reinforced structural extrusion profiles, guaranteeing protection against severe storms, high impact, and forced entry.
Sourcing architectural glazing systems internationally requires strict compliance, transparent supply chains, and zero-defect structural engineering. Window Wurx Industry Co., Ltd. delivers absolute reliability.
Every profile design undergoes rigorous structural, air infiltration (AS4420.4), water penetration (AS4420.5), and ultimate limit state wind pressure testing. We provide certified compliance documentation for European, Australian, and North American building codes.
Our in-house engineering lab specializes in polyamide (PA66GF25) thermal break integration and heavy-load hydraulic pivot hinge design, supporting door leaves up to 1000 kg load capacity and heights exceeding 6 meters.
Equipped with 3 fully automated German CNC machining centers, precision corner-crimping lines, and automated double-glazing lines in Foshan. We process bespoke custom orders with high repeatability and strict dimensional tolerances.
Long-haul ocean transit requires flawless packing. Every door and window frame undergoes surface PE film wrapping, corner protective caps, shock-absorbing cellular bubble wrap, air-tight plastic sealing, and solid fumigation-free wooden crating.
Our engineering division assists architects and contractors with customized shop drawings, structural wind-load calculation modeling, thermal performance simulation (U-value calculations), and floor track installation details.
Eliminate intermediary markups. By managing profile extrusion, anodizing, powder coating, assembly, and quality control under one roof in Dali Town, Foshan, we ensure highly competitive pricing for global wholesale buyers and project developers.
Pivot doors represent the pinnacle of modern architectural entries, combining dramatic grandeur with high-load mechanical balancing. Here is how our structural engineering solves key architectural challenges.
Standard residential doors frequently suffer from panel deflection when manufactured at heights exceeding 2.8 meters. To eliminate warping and guarantee structural integrity under extreme wind loads, Window Wurx utilizes primary 6063-T6 architectural grade aluminum alloy with wall thicknesses ranging from 2.5mm to 4.0mm at high-stress pivot attachment points.
T6 heat treatment yields an ultimate tensile strength of no less than 205 MPa and a yield strength of 170 MPa. This structural rigidity allows our pivot doors to effortlessly carry double- and triple-glazed insulated glass units up to 1000 kg without frame sagging or operational drag over decades of use.
The heart of a pivot door is its hinge mechanism. Rather than traditional side-mounted butt hinges that transfer stress directly to the door jamb, pivot doors distribute their entire mass onto a floor-recessed hydraulic spindle anchor.
Historically, large pivot doors were prone to air infiltration and thermal bridging at the top and bottom head rails. Our design overcomes this via a multi-tiered sealing system:
| Performance Metric | Engineering Standard / Test Method | Window Wurx System Specification |
|---|---|---|
| Thermal Transmittance (U-Value) | ISO 10077-2 / NFRC 100 | Down to 1.2 W/m²K (with PA66 thermal break & Low-E Argon units) |
| Wind Load Resistance | AS4420.2 / EN 12210 | Class C5 / P3 (Up to 5000 Pa design wind pressure) |
| Air Infiltration / Tightness | AS4420.4 / EN 12207 | Class 4 (0.05 L/s·m² at 75 Pa) via dynamic drop-down perimeter seals |
| Water Penetration Resistance | AS4420.5 / EN 12208 | Up to 600 Pa with concealed sub-sill drain profiles |
| Acoustic Insulation Rating | ISO 140-3 / ASTM E90 | Rw 38 dB to 45 dB (depending on laminated glass build-up) |
| Surface Coating Durability | AAMA 2605 / Qualicoat Class 2 | 25-year anti-fading warranty (Fluorocarbon PVDF or Anodized 25μm) |
As global building codes demand net-zero carbon footprints and seamless indoor-outdoor luxury integration, architectural procurement strategies are evolving rapidly.
Architects are rejecting bulky 100mm door frames in favor of ultra-minimalist designs. The future belongs to structural glazing where the frame width is hidden within wall cavity surrounds, leaving only a 16mm–25mm visible aluminum edge. Sourcing trends prioritize manufacturers capable of bonding jumbo glass sheets (up to 3000mm x 6000mm) directly into structural aluminum extrusions.
Manual operation for massive 800kg entry doors is being superseded by concealed electro-mechanical automated drives. Leading importers now require pivot door extrusions prefabricated with internal wiring raceways for motor drives, motorized multipoint locking pins, facial recognition scanners, dynamic LED accent strip lighting, and home automation API compatibility (KNX, Crestron, Control4).
With stringent European Carbon Border Adjustment Mechanisms (CBAM) taking effect, international procurement officers are requiring environmental product declarations (EPDs). Sourcing is shifting toward manufacturers utilizing low-carbon primary aluminum smelted with hydropower, recycled scrap content (>75%), and non-VOC powder coating processes.
Global climate volatility has elevated hurricane-impact performance from a regional Florida specification to a global standard. Concurrently, Next-Gen Vacuum Insulated Glass (VIG) offering U-values below 0.6 W/m²K in an 8.3mm profile thickness is replacing bulky triple-pane units, demanding precision-milled aluminum frame profiles capable of handling ultra-thin high-vacuum seals.
The traditional back-and-forth of paper shop drawings is being replaced by direct digital integration. Modern B2B procurement leverages cloud-based parametric CAD models exported straight into factory 5-axis CNC cutters, drastically shortening production lead times from 8 weeks down to 18 days for custom architectural openings.
Key technical, logistical, and commercial inquiries answered by our senior export engineering team.
Our aluminum window and door systems hold official CE certification (EN 14351-1) for European market access, compliance testing for AS2047 and AS1288 (Australia/New Zealand), and certified air/water/structural test reports under NFRC/AAMA guidelines for North America. Full test laboratory reports can be provided during your project design phase.
Pivot doors present a unique sealing challenge at the threshold. We utilize automated mechanical drop-down seals (concealed bottom spring-loaded gaskets) that activate upon closing, combined with double EPDM weather-stripping seals around the frame perimeter and concealed sub-sill water drainage channels to guarantee resistance up to 600Pa water pressure.
Yes. Through high-precision thermal-break assembly, we can finish the outer aluminum profile in architectural PVDF fluorocarbon paint (e.g., Matt Black AAMA 2605) while providing an anodized finish, custom powder coat, or realistic heat-transfer woodgrain finish for the interior facing profile to match internal joinery.
Once final shop drawings are signed off and technical specifications confirmed, our standard manufacturing lead time is 25 to 35 days. For urgent project phases, our 20,000m² facility with 3 automated CNC lines allows us to prioritize high-capacity batch fabrication.
We implement a strict 5-layer export protective system: 1) Surface protective film, 2) EPE foam corner caps, 3) Bubble wrap shock-absorption wrap, 4) Sealed moisture-barrier plastic wrap, and 5) Fully enclosed fumigation-free plywood crates reinforced with internal steel strapping.
Absolutely. We offer flexible B2B partnership programs for window and door distributors, general contractors, and architectural developers. Partners receive direct factory pricing, comprehensive CAD sample libraries, physical profile display cases, and dedicated engineering support.
Consult with our lead structural facade engineers to review your project elevations, request certified shop drawings, or obtain an accurate factory-direct quotation.
